Description

Product details

The UTC UC3844/3845 are high performance fixed frequency current mode controllers that specifically designed for Off-Line and DC to DC converter applications with minimal external parts count. The differences between UC3844 and UC3845 are the under-voltage lockout thresholds. The UC3844 ideally suited to off-line applications with UVLO thresholds of 16V(ON) and 10V(OFF), and UC3845 has UVLO thresholds of 8.4V(ON) and 7.6V(OFF) for lower voltage applications.  FEATURES * Operation output switching frequency up to 500 kHz * Automatic feed forward compensation * Latching PWM for cycle-by-cycle current limiting * High current totem pole output * Internally trimmed reference with under voltage lockout * UVLO with hysteresis * Low startup and operating current
