Name: Tip122 Transistor 100V 5A TO-220 BY WXDH
Brand: wxdh
Price: 7.15 INR
Availability: InStock

Tip122 Transistor 100V 5A TO-220 BY WXDH

INR 7.15

Phone Number

08042755673

Please keep 0 before dialling the number.

Email Address sales@binarysemiconductors.com

Mon-Thu: 10 AM - 2 PM • Fri: 3 PM - 7AM

Other Website Visit our other website

Address Vijay Chambers, 23-B, Tribhuvan Rd, opp. Dreamland Cinema, Grant Road East, Shapur Baug, Grant Road

Mumbai, India, 400004

Description

• High DC Current Gain − hFE = 2500 (Typ) @ IC = 4.0 Adc • Collector−Emitter Sustaining Voltage − @ 100 mAdc VCEO(sus) = 60 Vdc (Min) − TIP120, TIP125 = 80 Vdc (Min) − TIP121, TIP126 = 100 Vdc (Min) − TIP122, TIP127 • Low Collector−Emitter Saturation Voltage − VCE(sat) = 2.0 Vdc (Max) @ IC = 3.0 Adc = 4.0 Vdc (Max) @ IC = 5.0 Adc • Monolithic Construction with Built−In Base−Emitter Shunt Resistors • Pb−Free Packages are Available
