Description

Product details

The R82 is constructed of metallized polyester film (wound or stacked technology) with radial leads of tinned wire. Radial leads are electrically welded to the contact metal layer on the ends of the capacitor winding. The capacitor is encapsulated with thermosetting resin in a box of material meeting the UL 94 V–0 requirements. Automotive grade devices meet the demanding Automotive Electronics Council's AEC–Q200 qualification requirements. Applications Typical applications include blocking, coupling, decoupling, timing, and oscillator circuits. Not suitable for across-theline application (see Suppressor Capacitors). Benefits • Voltage range: 50 – 400 VDC • Capacitance range: 0.001 – 4.7 µF • Lead Spacing: 5 mm • Capacitance tolerance: ±5%, ±10%, ±20% • Climatic category: 55/105/56 • Operating temperature range of −55°C to +105°C • RoHS compliance and lead-free terminations • Tape & Reel packaging in accordance with IEC 60286–2 • Self-healing • Automotive grade (AEC–Q200)
