Home Products MBRF30100CT TO-220F WXDH
 Plastic material u
 Plastic material u
COD not available
INTEGRATED CIRCUITS by WXDH

MBRF30100CT TO-220F WXDH - TO-220F PACKAGE

INR 11
Share with
Share this on :

Description

Product details

 Plastic material used carries Underwriters Laboratory Classifications 94V-0  Metal silicon junction, majority carrier conduction  Low power loss, high efficiency  High current capability, low forward voltage drop  High surge capability  For use in low voltage, high frequency inverters, free wheeling, and polarity protection applications  Guardring for overvoltage protection  High temperature soldering guaranteed: 260o C/10 seconds,0.25”(6.35mm)from case
