DIODE by WXDH
MBR30100CT 100V 30A TO-220 DIODE BY WXDH - TO-220 PACKAGE
INR 11
Enquire
Description
Plastic material used carries Underwriters Laboratory Classifications 94V-0 Metal silicon junction, majority carrier conduction Low power loss, high efficiency High current capability, low forward voltage drop High surge capability For use in low voltage, high frequency inverters, free wheeling, and polarity protection applications Guardring for overvoltage protection High temperature soldering guaranteed: 260o C/10 seconds,0.25”(6.35mm)from case Mechanical Data Cases: JEDEC TO-220 molded plastic Terminals: Leads solderable per MIL-STD-750, Method 2026 Polarity: As marked Mounting position: Any Mounting torque: 5 in. - lbs. max Weight: 0.08 ounce, 2.24 grams
Other Specifications
| VOLTAGE : | 100V |
| AMPERE : | 30A |
| DELIVERY TIME : | 10-14 DAYS |
