Name: KS8081RNBIA-TR
Brand: MICROCHIP
Price: 83 INR
Availability: InStock

Phone Number

08042755673

Please keep 0 before dialling the number.

Email Address sales@binarysemiconductors.com

Mon-Thu: 10 AM - 2 PM • Fri: 3 PM - 7AM

Other Website Visit our other website

Address Vijay Chambers, 23-B, Tribhuvan Rd, opp. Dreamland Cinema, Grant Road East, Shapur Baug, Grant Road

Mumbai, India, 400004

Description

The KSZ8081 is a single-supply 10BASE-T/100BASE-TX Ethernet physical-layer transceiver for transmission and reception of data over standard CAT-5 unshielded twisted pair (UTP) cable. The KSZ8081 is a highly-integrated PHY solution. It reduces board cost and simplifies board layout by using on-chip termination resistors for the differential pairs and by integrating a low-noise regulator to supply the 1.2V core. The KSZ8081MNX offers the Media Independent Interface (MII) and the KSZ8081RNB offers the Reduced Media Independent Interface (RMII) for direct connection with MII/RMII-compliant Ethernet MAC processors and switches. A 25 MHz crystal is used to generate all required clocks, including the 50 MHz RMII reference clock output for the KSZ8081RNB. The KSZ8081 provides diagnostic features to facilitate system bring-up and debugging in production testing and in product deployment. Parametric NAND tree support enables fault detection between KSZ8081 I/Os and the board. LinkMD® TDR-based cable diagnostics identify faulty copper cabling. The KSZ8081MNX and KSZ8081RNB are available in 32-pin, lead-free QFN packages
