Description

Product details

The IR2110/IR2113 are high voltage, high speed power MOSFET and IGBT drivers with independent high and low side referenced output channels. Proprietary HVIC and latch immune CMOS technologies enable ruggedized monolithic construction. Logic inputs are compatible with standard CMOS or LSTTL output, down to 3.3V logic. The output drivers feature a high pulse current buffer stage designed for minimum driver cross-conduction. Propagation delays are matched to simplify use in high frequency applications. The floating channel can be used to drive an N-channel power MOSFET or IGBT in the high side configuration which operates up to 500 or 600 volts.

Keywords

• 600 volts
• floating channel
• 33v logic
• standard cmos
• igbt drivers
• lsttl output
• ir2110strpbf mosfet
• independent high
• output drivers feature
• nchannel power mosfet
• high side configuration
• high frequency applications
