The STGAP2S is a single gate driver which provides galvanic isolation between the
gate driving channel and the low voltage control and interface circuitry.
The gate driver is characterized by 4 A capability and rail-to-rail outputs, making the
device also suitable for mid and high power applications such as power conversion
and motor driver inverters in industrial applications. The device is available in two
different configurations. The configuration with separated output pins allows to
independently optimize turn-on and turn-off by using dedicated gate resistors. The
configuration featuring single output pin and Miller CLAMP function prevents gate
spikes during fast commutations in half-bridge topologies. Both configurations
provide high flexibility and bill of material reduction for external components.
The device integrates UVLO and thermal shutdown protection functions to facilitate
the design of highly reliable systems. Dual input pins allow the selection of signal
polarity control and implementation of HW interlocking protection to avoid cross-
conduction in case of controller malfunction. The input to output propagation delay is
less than 75 ns, which delivers high PWM control accuracy. A standby mode is
available to reduce idle power consumption.
DS12541 - Rev 5 - March 2025
For further information, contact your local STMicroelectronics sales office.
